Features
• Amplifier
- 1 rack unit high; Removable rack-ears
- Class-D power amplifier
- Universal switching power supply unit
- Bridgeable 2 channel amplifier (HY2150 Only)
- Toroidal 100, 70 Volt output transformers
(HY2120T / HY2060T / HY1120T Only)
- Balanced euro block inputs
- RCA jack for stereo input
- RCA jack for link output
- Speaker output connectors with multiple
- Taps: 70 Volt, 100 Volt and 4 Ohm
- Low power consumption
- Versatile LED status indicators
- Amp protection circuits: over current, protect, over
temperature protect, input overload protect.
Specification
• Amplifier
- 1 rack unit high; Removable rack-ears
- Class-D power amplifier
- Universal switching power supply unit
- Bridgeable 2 channel amplifier (HY2150 Only)
- Toroidal 100, 70 Volt output transformers
(HY2120T / HY2060T / HY1120T Only)
- Balanced euro block inputs
- RCA jack for stereo input
- RCA jack for link output
- Speaker output connectors with multiple
- Taps: 70 Volt, 100 Volt and 4 Ohm
- Low power consumption
- Versatile LED status indicators
- Amp protection circuits: over current, protect, over
temperature protect, input overload protect.
Specification
| Model | HY1120T | HY2060T | HY2120T | HY2150 |
| Power Rating | 120W RMS | 2 x 60W RMS | 2 x 120W RMS | 2 x 150W RMS |
| Frequency Response | 50Hz-20KHz | |||
| Signal to Noise Ratio | >90dB | |||
| Distortion (THD) | <0.1% | |||
| Input Impedance | 22K Ohms | |||
| Dimensions (WxDxH) | 482.3x246.2x50.2mm | |||
